The cabin is made of aluminum alloy splicing, with superior thermal conductivity and smooth inner walls, which is conducive to temperature control inside the cabin and improves drying efficiency. The outer wall is coated with PTC heating film for uniform heating;
Tempered glass sealed window, allowing observation of internal conditions during operation;
The control system adopts a 7-inch color touch screen, which can display cabin temperature, pressure, running time, and alarm information. It is equipped with a one click start button, which is convenient and fast. The built-in program can be adjusted according to user needs (5 sets of standard programmers);
Vacuum pump, runs smoothly, has a fast evacuation speed, and is easy and fast to maintain.
Medical low-temperature vacuum drying cabinet is a medical equipment that places instruments and narrow tubes that cannot withstand high temperatures under negative pressure conditions, and uses the characteristic of the boiling point of water changing with air pressure to quickly dry the instruments. It is suitable for the rapid drying of various endoscopes, endoscopic biopsy forceps, test tubes, dressing bowls, catheters, ventilator coils, various plates and other instruments and items in hospital operating rooms, supply rooms, endoscopy centers and other departments.
Safety protection is used for drying under low temperature and low pressure conditions, effectively avoiding damage to the equipment caused by high temperatures;
Fast drying can achieve the drying of items in a relatively short time;
Widely applicable to various high-temperature resistant instruments, luminal instruments, etc;
Energy saving vacuum drying is carried out at lower temperatures, requiring less heat to achieve drying.
| Model | BKEC-ZK50 | BKEC-ZK100 |
|---|---|---|
| Dimensions | 530×800×1435 | 530×800×1690 |
| Dimensions inside the cavity | 320×220×700/50L | |
| Cabin structure | Single cabin, double-sided door opening | Double cabin, double-sided door opening |
| Appearance style | ABS spray painted panel and stainless steel surface spray painted outer cover | |
| Number of instrument trays | 2 | 4 |
| Drying time | 0-99min | |
| Temperature range | Adjust between room temperature and 60 ℃ | |
| Power | 2Kw | 3Kw |
| Power requirements | AC220V，50HZ | |
| Control method | Color touch screen control | |
